Unified AI Model Management: Centralized Architecture for Multiple Providers

Managing connectivity to multiple AI models from different providers can be complex and error-prone. A unified AI model management system provides a centralized approach to handle multiple providers, abstract away differences, and provide a consistent interface for your applications.

The Challenge of Multi-Provider AI

Modern AI applications often need to work with multiple providers:

• Provider Diversity: OpenAI, Anthropic, Google, Azure, AWS, and more
• API Differences: Each provider has unique endpoints, authentication, and response formats
• Cost Optimization: Different providers offer different pricing and capabilities
• Reliability: Need fallback options when providers are unavailable
• Complexity: Managing multiple API keys, rate limits, and error handling

:::tip Unified Management Benefits A unified AI model management system can reduce development time by 60% and improve reliability by providing automatic fallbacks and load balancing. :::

Core Architecture Patterns

1. Provider Abstraction Layer

The foundation of unified management is abstracting provider differences behind a consistent interface.

from abc import ABC, abstractmethod
from typing import Dict, Any, Optional
import asyncio

class AIProvider(ABC):
    """Abstract base class for AI providers"""

    @abstractmethod
    async def generate_text(self, prompt: str, model: str, **kwargs) -> str:
        """Generate text using the provider's API"""
        pass

    @abstractmethod
    async def get_models(self) -> list:
        """Get available models from this provider"""
        pass

    @abstractmethod
    async def get_cost_estimate(self, prompt: str, model: str) -> float:
        """Estimate cost for a request"""
        pass

class OpenAIProvider(AIProvider):
    """OpenAI provider implementation"""

    def __init__(self, api_key: str):
        self.api_key = api_key
        self.client = openai.AsyncOpenAI(api_key=api_key)

    async def generate_text(self, prompt: str, model: str, **kwargs) -> str:
        try:
            response = await self.client.chat.completions.create(
                model=model,
                messages=[{"role": "user", "content": prompt}],
                **kwargs
            )
            return response.choices[0].message.content
        except Exception as e:
            raise AIProviderError(f"OpenAI error: {str(e)}")

    async def get_models(self) -> list:
        models = await self.client.models.list()
        return [model.id for model in models.data]

    async def get_cost_estimate(self, prompt: str, model: str) -> float:
        # OpenAI pricing per 1K tokens
        pricing = {
            "gpt-4": 0.03,
            "gpt-3.5-turbo": 0.002,
            "gpt-4-turbo": 0.01
        }
        estimated_tokens = len(prompt.split()) * 1.3
        return (estimated_tokens / 1000) * pricing.get(model, 0.01)

class AnthropicProvider(AIProvider):
    """Anthropic provider implementation"""

    def __init__(self, api_key: str):
        self.api_key = api_key
        self.client = anthropic.AsyncAnthropic(api_key=api_key)

    async def generate_text(self, prompt: str, model: str, **kwargs) -> str:
        try:
            response = await self.client.messages.create(
                model=model,
                max_tokens=kwargs.get('max_tokens', 1000),
                messages=[{"role": "user", "content": prompt}]
            )
            return response.content[0].text
        except Exception as e:
            raise AIProviderError(f"Anthropic error: {str(e)}")

    async def get_models(self) -> list:
        return ["claude-3-opus-20240229", "claude-3-sonnet-20240229", "claude-3-haiku-20240307"]

    async def get_cost_estimate(self, prompt: str, model: str) -> float:
        pricing = {
            "claude-3-opus-20240229": 0.015,
            "claude-3-sonnet-20240229": 0.003,
            "claude-3-haiku-20240307": 0.00025
        }
        estimated_tokens = len(prompt.split()) * 1.3
        return (estimated_tokens / 1000) * pricing.get(model, 0.003)

2. Unified Model Manager

The unified manager coordinates multiple providers and provides a single interface.

class UnifiedAIManager:
    """Unified AI model management system"""

    def __init__(self):
        self.providers: Dict[str, AIProvider] = {}
        self.model_mapping: Dict[str, str] = {}
        self.health_status: Dict[str, bool] = {}
        self.usage_metrics: Dict[str, Dict] = {}

    def register_provider(self, name: str, provider: AIProvider):
        """Register a new AI provider"""
        self.providers[name] = provider
        self.health_status[name] = True
        self.usage_metrics[name] = {
            'requests': 0,
            'errors': 0,
            'total_cost': 0.0,
            'last_used': None
        }

    def map_model_to_provider(self, model_name: str, provider_name: str):
        """Map a model name to a specific provider"""
        self.model_mapping[model_name] = provider_name

    async def generate_text(self, prompt: str, model: str, **kwargs) -> str:
        """Generate text using the best available provider"""

        # Determine which provider to use
        provider_name = self.model_mapping.get(model, self._select_best_provider(model))

        if not provider_name or provider_name not in self.providers:
            raise ValueError(f"No provider available for model: {model}")

        provider = self.providers[provider_name]

        try:
            # Attempt the request
            result = await provider.generate_text(prompt, model, **kwargs)

            # Update metrics
            self._update_metrics(provider_name, success=True)

            return result

        except Exception as e:
            # Update error metrics
            self._update_metrics(provider_name, success=False)

            # Try fallback provider
            fallback_provider = self._get_fallback_provider(provider_name)
            if fallback_provider:
                return await fallback_provider.generate_text(prompt, model, **kwargs)

            raise AIProviderError(f"All providers failed for model {model}: {str(e)}")

    def _select_best_provider(self, model: str) -> Optional[str]:
        """Select the best provider based on health, cost, and availability"""
        available_providers = [
            name for name, is_healthy in self.health_status.items()
            if is_healthy and name in self.providers
        ]

        if not available_providers:
            return None

        # Simple selection: prefer providers with fewer errors
        best_provider = min(
            available_providers,
            key=lambda p: self.usage_metrics[p]['errors']
        )

        return best_provider

    def _get_fallback_provider(self, failed_provider: str) -> Optional[AIProvider]:
        """Get a fallback provider when the primary one fails"""
        available_providers = [
            (name, provider) for name, provider in self.providers.items()
            if name != failed_provider and self.health_status[name]
        ]

        if available_providers:
            return available_providers[0][1]

        return None

    def _update_metrics(self, provider_name: str, success: bool):
        """Update usage metrics for a provider"""
        if provider_name in self.usage_metrics:
            self.usage_metrics[provider_name]['requests'] += 1
            if not success:
                self.usage_metrics[provider_name]['errors'] += 1
            self.usage_metrics[provider_name]['last_used'] = time.time()

    async def get_available_models(self) -> Dict[str, list]:
        """Get all available models from all providers"""
        models = {}
        for name, provider in self.providers.items():
            try:
                models[name] = await provider.get_models()
            except Exception:
                models[name] = []
        return models

    def get_health_status(self) -> Dict[str, bool]:
        """Get health status of all providers"""
        return self.health_status.copy()

    def get_usage_metrics(self) -> Dict[str, Dict]:
        """Get usage metrics for all providers"""
        return self.usage_metrics.copy()

3. Configuration Management

Centralized configuration for managing multiple providers.

import yaml
from dataclasses import dataclass
from typing import Dict, Any

@dataclass
class ProviderConfig:
    name: str
    api_key: str
    base_url: Optional[str] = None
    timeout: int = 30
    max_retries: int = 3
    rate_limit: Optional[int] = None

class ConfigurationManager:
    """Manage configuration for multiple AI providers"""

    def __init__(self, config_path: str = "ai_config.yaml"):
        self.config_path = config_path
        self.config = self._load_config()

    def _load_config(self) -> Dict[str, Any]:
        """Load configuration from YAML file"""
        try:
            with open(self.config_path, 'r') as file:
                return yaml.safe_load(file)
        except FileNotFoundError:
            return self._get_default_config()

    def _get_default_config(self) -> Dict[str, Any]:
        """Get default configuration template"""
        return {
            'providers': {
                'openai': {
                    'api_key': '${OPENAI_API_KEY}',
                    'base_url': 'https://api.openai.com/v1',
                    'timeout': 30,
                    'max_retries': 3
                },
                'anthropic': {
                    'api_key': '${ANTHROPIC_API_KEY}',
                    'base_url': 'https://api.anthropic.com',
                    'timeout': 30,
                    'max_retries': 3
                }
            },
            'model_mapping': {
                'gpt-4': 'openai',
                'gpt-3.5-turbo': 'openai',
                'claude-3-opus': 'anthropic',
                'claude-3-sonnet': 'anthropic',
                'claude-3-haiku': 'anthropic'
            },
            'fallback_strategy': 'round_robin',
            'health_check_interval': 60,
            'cost_tracking': True
        }

    def get_provider_config(self, provider_name: str) -> ProviderConfig:
        """Get configuration for a specific provider"""
        if provider_name not in self.config['providers']:
            raise ValueError(f"Provider {provider_name} not found in configuration")

        provider_config = self.config['providers'][provider_name]

        # Resolve environment variables
        api_key = self._resolve_env_var(provider_config['api_key'])

        return ProviderConfig(
            name=provider_name,
            api_key=api_key,
            base_url=provider_config.get('base_url'),
            timeout=provider_config.get('timeout', 30),
            max_retries=provider_config.get('max_retries', 3),
            rate_limit=provider_config.get('rate_limit')
        )

    def _resolve_env_var(self, value: str) -> str:
        """Resolve environment variable references"""
        if value.startswith('${') and value.endswith('}'):
            env_var = value[2:-1]
            return os.getenv(env_var, '')
        return value

    def get_model_mapping(self) -> Dict[str, str]:
        """Get model to provider mapping"""
        return self.config.get('model_mapping', {})

    def save_config(self):
        """Save current configuration to file"""
        with open(self.config_path, 'w') as file:
            yaml.dump(self.config, file, default_flow_style=False)

Implementation Example

Here’s a complete example of setting up and using the unified AI management system:

import asyncio
import os
from typing import Dict, Any

async def setup_unified_ai_manager():
    """Set up a complete unified AI management system"""

    # Initialize configuration
    config_manager = ConfigurationManager()

    # Initialize the unified manager
    ai_manager = UnifiedAIManager()

    # Register providers
    for provider_name in ['openai', 'anthropic']:
        try:
            provider_config = config_manager.get_provider_config(provider_name)

            if provider_name == 'openai':
                provider = OpenAIProvider(provider_config.api_key)
            elif provider_name == 'anthropic':
                provider = AnthropicProvider(provider_config.api_key)

            ai_manager.register_provider(provider_name, provider)
            print(f"✅ Registered provider: {provider_name}")

        except Exception as e:
            print(f"❌ Failed to register {provider_name}: {e}")

    # Set up model mapping
    model_mapping = config_manager.get_model_mapping()
    for model, provider in model_mapping.items():
        ai_manager.map_model_to_provider(model, provider)

    return ai_manager

async def example_usage():
    """Example of using the unified AI manager"""

    # Set up the manager
    ai_manager = await setup_unified_ai_manager()

    # Example prompts
    prompts = [
        "Explain quantum computing in simple terms",
        "Write a Python function to calculate fibonacci numbers",
        "Summarize the benefits of unified AI management"
    ]

    # Generate responses using different models
    models = ['gpt-3.5-turbo', 'claude-3-haiku', 'gpt-4']

    for i, prompt in enumerate(prompts):
        model = models[i % len(models)]

        try:
            print(f"\n🤖 Using model: {model}")
            print(f"📝 Prompt: {prompt[:50]}...")

            response = await ai_manager.generate_text(prompt, model, max_tokens=150)

            print(f"✅ Response: {response[:100]}...")

        except Exception as e:
            print(f"❌ Error: {e}")

    # Show metrics
    print(f"\n📊 Usage Metrics:")
    metrics = ai_manager.get_usage_metrics()
    for provider, data in metrics.items():
        print(f"  {provider}: {data['requests']} requests, {data['errors']} errors")

## Run the example

```python
if __name__ == "__main__":
    asyncio.run(example_usage())

Configuration File Example

Create a ai_config.yaml file for your configuration:

providers:
  openai:
    api_key: ${OPENAI_API_KEY}
    base_url: https://api.openai.com/v1
    timeout: 30
    max_retries: 3
    rate_limit: 3500  # requests per minute

  anthropic:
    api_key: ${ANTHROPIC_API_KEY}
    base_url: https://api.anthropic.com
    timeout: 30
    max_retries: 3
    rate_limit: 500

  google:
    api_key: ${GOOGLE_AI_API_KEY}
    base_url: https://generativelanguage.googleapis.com
    timeout: 30
    max_retries: 3

model_mapping:
  gpt-4: openai
  gpt-3.5-turbo: openai
  gpt-4-turbo: openai
  claude-3-opus: anthropic
  claude-3-sonnet: anthropic
  claude-3-haiku: anthropic
  gemini-pro: google

fallback_strategy: round_robin
health_check_interval: 60
cost_tracking: true

Best Practices

1. Provider Selection Strategy

class ProviderSelectionStrategy:
    """Different strategies for selecting providers"""

    @staticmethod
    def cost_based(providers: Dict[str, AIProvider], prompt: str, model: str) -> str:
        """Select provider based on cost"""
        costs = {}
        for name, provider in providers.items():
            try:
                costs[name] = provider.get_cost_estimate(prompt, model)
            except:
                costs[name] = float('inf')

        return min(costs, key=costs.get)

    @staticmethod
    def performance_based(providers: Dict[str, AIProvider], metrics: Dict) -> str:
        """Select provider based on performance metrics"""
        performance_scores = {}
        for name in providers:
            provider_metrics = metrics.get(name, {})
            error_rate = provider_metrics.get('errors', 0) / max(provider_metrics.get('requests', 1), 1)
            performance_scores[name] = 1 - error_rate

        return max(performance_scores, key=performance_scores.get)

    @staticmethod
    def round_robin(providers: Dict[str, AIProvider], last_used: Dict[str, float]) -> str:
        """Select provider using round-robin strategy"""
        if not last_used:
            return list(providers.keys())[0]

        # Find provider used least recently
        return min(last_used, key=last_used.get)

2. Error Handling and Retry Logic

import asyncio
from functools import wraps

def retry_with_backoff(max_retries: int = 3, base_delay: float = 1.0):
    """Decorator for retry logic with exponential backoff"""

    def decorator(func):
        @wraps(func)
        async def wrapper(*args, **kwargs):
            last_exception = None

            for attempt in range(max_retries):
                try:
                    return await func(*args, **kwargs)
                except Exception as e:
                    last_exception = e

                    if attempt < max_retries - 1:
                        delay = base_delay * (2 ** attempt)
                        await asyncio.sleep(delay)

            raise last_exception

        return wrapper
    return decorator

class RobustAIManager(UnifiedAIManager):
    """Enhanced AI manager with robust error handling"""

    @retry_with_backoff(max_retries=3)
    async def generate_text(self, prompt: str, model: str, **kwargs) -> str:
        """Generate text with retry logic"""
        return await super().generate_text(prompt, model, **kwargs)

Monitoring and Observability

import logging
from datetime import datetime

class AIConnectivityMonitor:
    """Monitor AI connectivity and performance"""

    def __init__(self):
        self.logger = logging.getLogger('ai_connectivity')
        self.metrics = {
            'requests': 0,
            'errors': 0,
            'latency': [],
            'costs': []
        }

    def log_request(self, provider: str, model: str, latency: float, cost: float, success: bool):
        """Log a request for monitoring"""
        self.metrics['requests'] += 1
        self.metrics['latency'].append(latency)
        self.metrics['costs'].append(cost)

        if not success:
            self.metrics['errors'] += 1

        self.logger.info(
            f"Request to {provider}/{model}: "
            f"latency={latency:.2f}s, cost=${cost:.4f}, success={success}"
        )

    def get_health_report(self) -> Dict[str, Any]:
        """Generate health report"""
        total_requests = self.metrics['requests']
        error_rate = self.metrics['errors'] / max(total_requests, 1)
        avg_latency = sum(self.metrics['latency']) / max(len(self.metrics['latency']), 1)
        total_cost = sum(self.metrics['costs'])

        return {
            'total_requests': total_requests,
            'error_rate': error_rate,
            'avg_latency': avg_latency,
            'total_cost': total_cost,
            'timestamp': datetime.now().isoformat()
        }

Conclusion

A unified AI model management system provides significant benefits:

• Simplified Development: Single interface for multiple providers
• Improved Reliability: Automatic fallbacks and error handling
• Cost Optimization: Intelligent provider selection based on cost and performance
• Better Monitoring: Centralized metrics and health monitoring
• Scalability: Easy to add new providers and models

:::tip Implementation Priority Start with a simple provider abstraction layer, then gradually add advanced features like load balancing and monitoring. :::

The key to success is starting with a solid foundation and gradually building more sophisticated features as your needs grow. Remember to monitor performance and costs to ensure your unified system is providing the expected benefits.
